Glyph Thunderbolt 3 NVMe Dock

Brand: Glyph Production Technologies

Features:

• Offers 1TB of storage space – The Glyph Thunderbolt 3 Dock contains 1TB NVMe M.2 SSD and provides up to data transfer speed of up to 1,500 MB/s
• Simplifies your workstation setup – The NVMe Docking System streamlines your Directory Information Tree by providing multiple, versatile ports. This keeps your table decluttered from long cable runs
• Offers high data throughput – The Thunderbolt 3 Dock provides up to 40GB/s of throughput for video and digital files
• Supports daisy-chaining of up to 5 Thunderbolt 3 monitors – You can connect up to 5 Thunderbolt 3 monitors via DisplayPort 1.2 terminals. This reduces the amount of cabling on your work desk
• Compatible with Mac and Windows – The docking system comes preformatted for Mac computers. It is Time Machine-compatible. You can do a simple reformat to use the hard drive for Window’s systems

PartNumber: GLPH_GLTB_V

Details: Glyph Thunderbolt 3 NVMe Dock with 1TB NVMe M.2 SSD

The Glyph Thunderbolt 3 NVMe Dock is an excellent solution in simplifying your workstation setup. It features multiple, versatile ports. The NVMe Docking System has two Thunderbolt 3 ports with up to 40GB/s throughput. The added non-volatile memory express 1TB SSD can deliver up to 1500 MB/s of transfer speed. You can format the NVMe Dock as it is compatible with Windows 10, Mac OS X, and newer operating systems.

One of Thunderbolt 3 NVMe Dock ports can be connected to a single peripheral or daisy-chain up to 5 devices. The DisplayPort 1.2 ports support Single 5K and Dual 4K Displays. The docking system is also equipped with a 3.5mm headphone and microphone jack. It even has an RJ45 port to connect your Ethernet cable.

TECHNICAL SPECS:

• Type: Non-Volatile Memory Express Docking System
• Storage Capacity: 1TB
• Interface Connection: SD (UHS-II) Memory Card Slot, USB 3.1 Gen 2 Type-C, 3.5mm Audio Output, 3.5mm Audio Microphone Output, RJ45 Ethernet, M.2 Socket for NVMe SSD, 2x DisplayPort 1.2, 2x USB 3.0 Type-A, 2x Thunderbolt 3
• Compatible With: Mac OS 10.X+, Windows 10 or Newer Versions with Thunderbolt 3 Port
• Supported Drives: M.2 Socket = PCI-e Gen.3 x2
• Supported Resolutions: Single 5K Display at 60Hz, Dual 4K Display at 60Hz
• Data Transfer Rate via Thunderbolt 3: 40 GB/s
• Data Transfer Rate with NVMe SSD: Up to 1500 MB/s
• Data Transfer Rate with SD Memory Card: Up to 270 MB/s
• Data Transfer Rate via USB 3.0 Type-A: 5Gbps / 5V at 1.2A
• Data Transfer Rate via USB 3.1 Type-C: 5V at 3A
• Cooling Feature: Passive Heat Dissipation
• Power Source: 87W External Power Supply
• Dimensions: 9.4 x 3.8 x 0.9″

Model: GLPH_GLTB_V
