Focusrite RED16 Line.
The Red 16Line is a professional 64-in/64-out audio interface designed for high-end studios, offering exceptional conversion quality, ultra-low latency performance, and seamless integration with both Pro Tools | HD and Thunderbolt 3 workflows.
Featuring Focusrites premium Red Evolution mic preamps, advanced A-D/D-A conversion, and network audio expansion via Ethernet, the Red 16Line delivers the flexibility and performance required for demanding recording, mixing, and post-production environments. With both DigiLink and Thunderbolt connections, switching between Pro Tools | HD and a secondary DAW is fast and effortless, without the need to change hardware configurations.
Its high-performance converters provide up to 118dB A/D and 121dB D/A dynamic range, offering exceptional clarity, detail, and low conversion latency. Ultra-low round-trip latency allows you to monitor and mix directly through your DAW with plug-ins active, simplifying recording workflows and eliminating the need for separate monitoring setups.
The Red 16Line features 16 line inputs and 16 line outputs via D-sub connections, along with dedicated monitor outputs. Two digitally controlled Red Evolution mic preamps provide up to 63dB of ultra-clean gain, with stereo linking, independent phantom power, high-pass filtering, phase reverse, and Focusrites Air mode for the open, detailed sound inspired by the classic ISA transformer preamps.
With an optional dual-port Dante expansion card, the Red 16Line can integrate into networked audio environments, providing additional channels over Ethernet with low latency and high sample-rate support.
Features
- 64-in/64-out professional audio interface
- Pro Tools | HD DigiLink and dual Thunderbolt 3 connectivity
- Ultra-low latency A-D/D-A conversion with up to 118dB A/D and 121dB D/A dynamic range
- Two Red Evolution mic preamps with up to 63dB gain
- Air mode, high-pass filter, phase reverse, phantom power, and stereo linking
- 16 line inputs and 16 line outputs via D-sub connectors
- Dedicated monitor outputs
- Expandable with Dante Ethernet networking
- Seamless switching between Pro Tools | HD and other DAWs
- Focusrite Control software for flexible monitoring and routing
Included Software
- Focusrite Control
- RedNet PCIe Drivers
- Audinate Dante Controller
- Red 2 & 3 Plug-in Suite
- Softube Time & Tone Bundle
What’s in the Box
- Red 16Line
- Power supply
- Thunderbolt 3 cable
