JBL CPi2000 Cinema Processor
The CPi2000 is a professional-grade audio processor designed to manage complex signal routing and acoustic tuning in studio and production environments. This unit serves as a central hub for multitrack recording and playback workflows, handling digital and analog inputs with precision while delivering real-time system monitoring and fault detection across multiple output channels and amplified monitoring paths.
Signal Management & I/O
Comprehensive connectivity includes digital HD-25 balanced input (110 Ohms, 0.5–10 Vpp), analog balanced/unbalanced HD-25 input (50K or 25K Ohms impedance, +14.2 dBu max), XLR mic input with 40 dB gain and>113dB E.I.N. at 20 kHz, and RCA music input (25K Ohms, +14.2 dBu max). Output flexibility spans 10 HD-15 analog connectors supporting passive, bi-amp, or tri-amp monitoring configurations, plus a 25-pin analog output for integration with third-party mixing consoles and outboard gear.
Processing & Room Tuning
The processor features DSP-based audio enhancement paired with a 1/3 octave graphic equalizer and variable crossover presets for adaptive room acoustics compensation and monitor blending. A large LCD display provides real-time channel status monitoring and intuitive global output volume control, while amplifier and speaker fault detection via RJ45 connection ensures monitoring reliability and alerts engineers to potential issues before they affect tracking or mixing sessions.
Key Features
- Professional-grade DSP processing for audio enhancement and volume control
- Digital HD-25 balanced input: 110 Ohms impedance, 0.5–10 Vpp
- Analog HD-25 balanced/unbalanced input: 50K Ohms (balanced) or 25K Ohms (unbalanced), +14.2 dBu max
- XLR mic input with 40 dB total gain and>113dB E.I.N. at 20 kHz
- Non-sync (music) RCA input: 25K Ohms impedance, +14.2 dBu max
- 10 HD-15 analog output connectors for passive, bi-amp, or tri-amp configurations
- 25-pin analog output connector for third-party system integration
- 1/3 octave graphic equalizer with variable crossover presets for room tuning
- Large LCD display for channel status monitoring and output volume setup
- Fault detection for amplifiers and speakers via RJ45 connector
- System fault detection and real-time diagnostics
The CPi2000 combines comprehensive I/O flexibility, adaptive room correction, and integrated system diagnostics to deliver professional-grade audio control for recording studios and production facilities.
